200 HP Superior Boiler with Heat Exchanger 1063

Description

This unit was built to heat large volumes of water on a temporary site. It can provide steam at a rate of 4,770 kW, or heat a liquid at a rate of 2,051 kW, or a combination of the two. The Power Flame boiler runs on No. 2 Oil or Natural Gas, providing flexibility.

The unit is ideal for plant shutdowns, sea ring heating and emergency backup for building heating. To provide flexibility, the unit does contain a circulating pump for the heat exchanger, and a generator for the electrical service.

Building dimensions are 15.2×3.4×3.7 meters.

This unit is for rent or sale. Contact info@arcticboilers.com or call 780-955-2723

Boiler Details

  • Manufacturer: Superior Boiler Works, Inc.
  • HP: 200
  • Max Working Pressure: 1034KPA (150 psig)
  • Year Built: 2015
  • CRN W2044.2

Burner Details

  • Manufacturer: Power Flame
  • Model: C4-GO-30C
  • Firing rate (BTU/hr) 6,276,000
  • Fuel: Natural Gas / No. 2 Oil.
  • Max No. 2 Oil Usage: 41 Liter per hour
  • Max Natural Gas Pressure: 8 PSI
  • Max Natural Gas Usage: 240 Cubic meter per hour

Heat Exchanger Details

  • Manufacturer: Advanced Industrial Components inc.
  • Max Working Pressure: 1303 KPA
  • Year Built: 2015
  • CRN
  • Duty 2,051 kW

Generator

  • Manufacturer: ISUZU
  • Size: 54 KW
  • Year Built: 2015
  • Voltage: 208 / 120 V
  • Phase: Three
  • Max Amps: 187

Building Details

  • Manufacture: Arctic Boilers & Fabricating Ltd
  • Volume of Water Tank: 16,310 Liter
  • Volume of Fuel Tank: 11,214 Liter
  • Voltage: 120/208v
  • Phase: 3Y
  • Amperage: 60A
  • Total Length: 15.2M
  • Total Height: 3.4M
  • Total Width: 3.66M
  • Steam connection: one 2-inch NPT with Hammer Union
  • Gas Connection: 2-inch NPT, 6 PSI
